1 fiber +1 rj45 port 10 100mbps inner card of fiber ethernet media converter
Over View
The Ethernet media converters are designed to transmit and receive 10/100Mbps data over multimode or single mode optical fiber. The electrical interface will Auto-Negotiate to a 10Mbps, or 100Mbps Ethernet rate without any adjustments. The optical interface operates at a 100Mbps Ethernet rate. LED indicators are provided for rapidly ascertaining equipment operating status.
Key Features
1. Plug and play, high performance, Low power consumption
2. Complies with IEEE802.3 (10BASE-T) and IEEE802.3u (100BASE-TX/FX) standards
3. Electrical port supports Auto-Negotiation for 10Mbps or 100Mbps, full duplex or half duplex data.
4. Automatic MDI/MDI-X crossover
5. Distances up to: 2 km Multimode, 25-120 km Single Mode
6. ST, SC, FC LC optical connectors
7. AC/DC powered
8. Status LED's for TX,FX LINK/ACT, POWER,100M to easily monitor network status
| Product Name | 1 fiber +1 rj45 port 10 100mbps inner card of fiber ethernet media converter |
| Brand Name | Handar |
| Model No: | HD-110SC-20A/B |
| Interface | 1xEthernet Port(RJ45),1xOptical Port |
| Optical Port | Available for 1310nm and 1550nm single mode, and 1310nm mutimode |
| Transfer Distance | Multi mode & Dual Fiber 550M Single mode & Single Fiber:25/40/60/80/100/120KM |
| communication mode | Full-Duplex and Half-Duplex Autonegotiation. |
| Available Speed: | Force 10 Mbps, Force100Mbps and Autodetective. 10/100 Mbps Full-Duplex and Half-Duplex Autonegotiation. |
| Packet Buffer | 1Mbit |
| Switching Delay | <5μs |
| IEEE Standard | IEEE802.3, IEEE802.3U,IEEE802.3X |
| Forwarding Mode | Store-and-forward |
| Connectors | RJ45,SC/ST/FC/LC Optical |
| Power Requirment: | Input 12VDC-48VDC |
| LED Indicators | Power Status, Speed Status,Fxlink/Act,TXLink/Act |
| Consumption | Max5.8W |
| Operating humidity | 10%-95% RH(Non-Condensing) |
| Operating temperating | -30℃~+70 ℃ |
| Installation: | DIN-Rail or Panel Mounting |
| Housing | Metal Enclosure |
| Protection Class | IP40 |
| Over-load Protection | Yes |
| Reverse Connection Protection | Yes |
| Certification | CE,ROHS,FCC |
| Item Diamention: | 100x70x26mm |
| Net Weight | 0.15Kg |
| Warranty | 3 year warranty(1 yeas warranty for power adapter) |
|
|
